Van Belle Nursery

  • Snow Load: 2,4 kPa
  • Wind Load: (Q 1/10): 0,33 kPa

Technical specifications

  • Width: 30′
  • Length: 270′
  • Number of greenhouses: 16
  • Arch spacing: 6′
  • Surface area (ft2): 97200

Covering:

Double poly (7,2mil) + Anti-Drip Treatment

Equipment:

  • Heating:
    • Modine Furnace
  • Mechanical Ventilation:
    • Mid-Roof Vent
    • Motorized roll-up peak vents with relay box
    • 18″ HAF fan (12 per greenhouse)
  • Natural Ventilation:
    • Roll-up (7′ high) with anti-flapping 2” tube
  • Poly skirt (double)
  • Doors:
    • Double sliding door: 144” x 98”
    • Steel baseboard
  • End Wall:
    • Double polycarbonate

Foundations:

  • Concrete piers
  • Greenhouse Model: Ovaltech III
  • Perrenials & Annuals (on the ground)
  • Location: Abbotsford, British Columbia
